WALL-AND-CEILING-MOUNTED LED LIGHT FITTING VIDEX BHD01 9W 2400-3200-4300K BLACK

WALL-AND-CEILING-MOUNTED LED LIGHT FITTING VIDEX BHD01 9W 2400-3200-4300K BLACK

Index: VL-BHD01-09CBB

Add to favorites Add to compare

Parameters

EAN:

4820246487771
On-mode power (Pon):

9 W
Luminous flux of the luminaire:

300 Lm
Useful luminous flux of the contained light source (Φuse):

1200 Lm
Light source or containing product:

Containing product
Energy efficiency class of the contained light source:

E
- Correlated color temperature:

  2400K (warm white), 3200K (warm white), 4300K (neutral white)
- Rated voltage, frequency:

  AC 220-240 V, 50/60 Hz
- Beam angle:

  160°
- Place of installation :

  Ceiling, Flat surface, Wall
- Place of application:

  indoor, outdoor
- Rated current:

  45 mA
- Displacement factor (cos φ1):

  0.9
- Color rendering index (CRI):

  Ra > 90
- Lifetime (L70B50):

  50000 h
- On/Off cycles:

  25000
- Housing colour:

  Black
- Impact protection:

  IK08
- Input interface:

  Terminal block
- Useful luminous flux of the light source reference:

  in a sphere (360°)
- Electric shock protection class:

  II
- Minimum distance from the illuminated object:

  0.5 m
- Diffuser material:

  Polycarbonate (PC)
- Ultraviolet radiation:

  no
- Motion sensor:

  no
- Operating temperature range:

  -30° +50°C
- Dimmable:

  no
- Light source replaceable:

  no
- Mercury content:

  Does not contain
- Ingress protection:

  IP65
- Housing material:

  Iron alloy, ABS
- Height:

  140 mm
- Width:

  140 mm
- Depth:

  78 mm
- In the package:

  1 pc.
- Outer box:

  30 pcs.
- Unit nett weight:

  450g
- Warranty:

  3 years

See all specifications

Description

Wall-And-Ceiling-Mounted LED Light Fitting VIDEX BHD01 9W 2400–3200–4300K is designed for both indoor and outdoor use. It is ideal for illuminating building facades, entrance areas, spaces under canopies, balconies, terraces, staircases, and rooms with high humidity levels. In addition to its high level of dust and moisture protection (IP65), the luminaire allows operation with different light color temperatures. It ensures natural color rendering (Ra > 90) and offers excellent resistance to external influences. The fixture is surface-mounted and can be installed on both vertical and horizontal surfaces. The compact dimensions are only 140×78mm.

A key feature of this model is the adjustable color temperature that can be set according to your needs:
- 2400K (warm light): suitable for decorative illumination of facades, terraces, and relaxation areas, creating a cozy atmosphere.
- 3200K (warm light): provides comfortable lighting for yards, private houses, and facade illumination, beautifully highlighting natural wood and plant tones.
- 4300K (neutral white light): a universal option for lighting entrances, parking areas, yards, or walkways.

The color temperature can be adjusted using the color temperature adjuster located on the back of the luminaire housing, setting it to the desired light temperature (2400K, 3200K, or 4300K). Thanks to its minimalist and modern design, the luminaire will look stylish in any architectural style. The transparent frame around the diffuser creates a backlight effect and gives the fixture a visually lighter and elegant appearance.

TECHNICAL SPECIFICATIONS:
- Power – 9W
- Luminous flux – 300 Lm
- Color temperature – 2400–3200–4300K
- Luminous efficacy – 33 Lm/W
- Energy efficiency – B (UA) / E (EU)
- Beam angle – 160°
- Operating voltage – AC 220–240V
- Uniform, flicker-free illumination with instant start-up and no ultraviolet radiation
- Service life – 50 000 hours
- Number of ON/OFF cycles – 25 000
- Dust and moisture protection – IP65
- Impact protection – IK08

Manufactured from safe, high-quality materials. Designed for long-lasting use and backed by a 3-year warranty.
